This Sniper 2 EFI bundle pairs a complete, self-tuning Sniper 2 EFI throttle body kit with a matched HyperSpark ignition system for 8.2-inch deck small block Ford (5.0 base) engines - a distributor, ignition coil, and HyperSpark 2 ignition box - plus the Power Distribution Module (PDM) and a Bluetooth-capable in-line fuel system master kit, in a single coordinated upgrade. Fits Ford 260/289/302/5.0L V8 engines.
Key Features:
- Includes a HyperSpark distributor, coil, and ignition box matched to the 8.2 in. deck small block Ford application
- Includes the Power Distribution Module (PDM) with a wiring diagram to connect the system to dedicated circuits for a stress-free install
- Billet aluminum distributor housing with a Hall Effect crank trigger for a noise-free RPM signal to the ECU
- Integrated ignition coil bracket delivers up to 150 mJ of spark energy per second from idle to redline
- Patented clear installation cap eliminates guesswork when installing the distributor, with a built-in timing mark indicator
- Complete in-line fuel system included: 20 ft. of 3/8 in. Vapor Guard fuel hose, fuel pump, fuel pressure regulator, filters, hardware, and a bulkhead fitting
- Bluetooth module turns an iOS or Android smartphone into a tuning and monitoring interface, with a base map to get started and no laptop required
- Next-generation ECU with improved RF noise and interference resistance for reliable operation on older vehicle wiring
- Only four wiring connections required for the throttle body: Battery+, Battery-, Switched Ignition, and RPM
- Cast-in fuel crossover from the primary to secondary fuel rail
- Integrated transmission kickdown provisions for GM TH350/400, 200-4R/700R4 and Ford C4/C6 applications (transmission control kit and vehicle-specific harness sold separately)
- Supports up to 650 hp naturally aspirated or 575 hp under boost with four 100 lb/hr injectors
Specifications:
- Flange Style: 4150
- CFM: 800
- Fuel Pressure: 58.5 PSI
- Fuel Pump Flow Rating: 240 LPH
- Fuel System: Inline fuel system master kit
- Injector Size: 100 lb/hr @ 58.5 PSI
- Inlet/Outlet Size: 9/16-18 Female O-Ring (AN 6)
- MAP Sensor: 2 Bar
- Max Horsepower Rating: 650 naturally aspirated / 575 boosted
- Distributor Included: Ford Small Block, 8.2 in. Deck
- HyperSpark Ignition Kit: Ford Small Block 8.2 Deck
- User Interface: Bluetooth Module (3.5 in. or 5 in. handheld also compatible)
- Power Distribution Module: Yes
- Transmission Compatibility: All
- Part Number: 550-510-BPK-SBF
Fits Ford 260/289/302/5.0L V8 engines only. Nitrous control is not supported in Sniper 2 EFI software.
FAQ
Which engines does this bundle fit?
It's built for 8.2 in. deck small block Ford (5.0 base) engines - Ford 260/289/302/5.0L V8s - with a matched HyperSpark distributor.
What's included in the ignition portion of this bundle?
A HyperSpark distributor, ignition coil, and HyperSpark 2 ignition box, matched to the small block Ford application.
Does this bundle include the Power Distribution Module?
Yes, the PDM is included to simplify wiring, especially alongside the HyperSpark ignition system.
What fuel system is included?
A complete in-line master kit: 20 ft. of fuel hose, an in-line pump, a fuel pressure regulator, filters, hardware, and a bulkhead fitting.
Is nitrous control supported?
No, nitrous control is not supported in Sniper 2 EFI software.
