This retrofit column is a fit for a classic GM Impala, Caprice, or Chevy truck and does not require modification to the original vehicle. The original column is removed while saving the factory underdash mount and floor mount, then the new column installs in its place using the original installation pieces or Borgeson joints and shafting. It comes with a neutral safety switch and an id.Classic keyed ignition, and the shift pattern supports either a 3 or 4-speed automatic transmission. A shift linkage (new or original) is required and attaches to the lower shift arm on the column.
Specifications:
- Shifter location: Column shift
- Tilt: 8-position tilt
- Self-canceling turn signals: Yes
- 4-way flashers: Yes
- Neutral safety switch: Yes
- Horn: Yes
- Lower shaft: 1 inch, 48-spline
- Upper shaft: Fits 1969-1994 GM passenger car
- Lower tube diameter: 2 inches
- Upper tube diameter: 2 inches
- Wire plug: GM 3 7/8 inch + GM 4 1/4 inch
- Collapsible: No
- Transmission: Automatic
- Floor mount included: No
- Underdash mount included: Yes
- Gear shift indicator included: No
- Finish: Black powder coated steel
- Weight: 21.4 lbs
- Warranty: Limited lifetime
- Part Number: 1540760051
Vehicle Applications:
- 1971 Chevrolet Caprice
- 1971 Chevrolet Impala
- 1972 Chevrolet Caprice
- 1972 Chevrolet Impala
- 1973 Chevrolet Caprice
- 1973 Chevrolet Impala
- 1973 Chevrolet Truck
- 1974 Chevrolet Caprice
- 1974 Chevrolet Impala
- 1974 Chevrolet Truck
- 1975 Chevrolet Caprice
- 1975 Chevrolet Impala
- 1975 Chevrolet Truck
- 1976 Chevrolet Caprice
- 1976 Chevrolet Impala
- 1976 Chevrolet Truck
- 1977 Chevrolet Truck
- 1978 Chevrolet Truck
- 1979 Chevrolet Truck
- 1980 Chevrolet Truck
- 1981 Chevrolet Truck
- 1982 Chevrolet Truck
- 1983 Chevrolet Truck
A shift linkage (new or factory) is required for installation and attaches to the lower shift arm on the column. The original Impala/Caprice steering wheel bolts on directly with no adaptor needed, or an aftermarket wheel can be added using an adaptor to keep its grip surface in the stock location.
FAQ
Does this column require modifying the original vehicle?
No, it is designed as a bolt-in replacement using the factory underdash and floor mounts.
What transmissions does it support?
It supports either a 3-speed or 4-speed automatic transmission via the column's shift pattern; a shift linkage, new or factory, is required.
Does it include a shift indicator?
No, a gear shift indicator is not included and is sold separately.
What vehicles does this column fit?
It fits 1971-1976 Chevrolet Impala and Caprice, and 1973-1983 Chevrolet trucks.
