The APR Stage 3 System for the 2022+ Volkswagen Golf R and Audi S3 is the ultimate evolution of the EA888 Gen 4 platform - combining Garrett PowerMax GT2563S turbocharger support, APR's Multi-Port Injection fueling, and APR's Stage 3 ECU/TCU calibration into one factory-ECU-controlled ecosystem. The integrated MPI system works alongside the factory direct injection system under full ECU control, delivering the fuel capacity needed for true Stage 3+ power without a standalone controller. Available in 350 WTQ and 400 WTQ configurations with support for 91, 93, 100, 104 octane, and E85, the system has been validated at 3.12 seconds 0-60 MPH, an 11.16-second quarter mile at 123 MPH in full street trim at 3,000 density altitude - with 10-second capability at sea level - and 9.55 seconds 60-130 MPH, all while retaining OEM-style cold starts, drivability, and factory safety strategies.
APR APR 22-24 VW MK8 Golf R 2.0T Stage 3+ PowerMax + Port Injection Turbo System T4100011
Specifications:
| Brand | APR |
| California Proposition 65 | Yes |
| Category | Forced Induction |
| Drivetrain | AWD |
| ECU Software Included | Yes |
| Emission Code | 7 |
| 5680 | Yes |
| 5681 | Yes |
| Exhaust Pipe Inside Diameter | N/A |
| 5679 | N/A |
| Exhaust Pipe Outside Diameter | N/A |
| Exhaust Sound Level | N/A |
| 3390 | Performance |
| Kit Type | Turbo Kit |
| Manifold Material | N/A |
| Muffler Quantity | N/A |
| OEM Turbo Part # | 06Q145703F |
| OEM Turbo Part # | 06Q145703G |
| OEM Turbo Part # | 06Q145703H |
| OEM Turbo Part # | 06Q145703C |
| 3530 | N/A |
| Product Type | Turbocharger Systems |
| Software Included | Yes |
| Sub Category | Turbocharger Systems |
| Tail Pipe Tip Quantity | N/A |
| Turbo Brand | Garrett |
| 5683 | Oil |
| 5684 | Raw |
| 5685 | Yes |
| 5686 | Metal |
| Turbo Maximum Pressure | N/A |
| 5687 | Yes |
| 5688 | Yes |
| Turbo Type | Drop-in Turbo |
| Turbocharger | GT2563S |
| Turbocharger CARB EO # | D-871-2 |
| Version | AWD MQB EVO |
| Warning | California Proposition 65 |
| Description_ABR | S3+ PMAX MPI |
| Description_SHO | S3+ PMAX+MPI, GOLF R |
| Description_INV | MK8 GOLF R S3+ PMAX W. MPI |
| Description_ASC | Factory 10,000 mile oil intervals are excessive. Cut oil intervals in half when upgrading to Stage 3 Turbo Systems.. To add an additional layer of protection, use a high performance oil matching the factory weight and minimum factory specs. |
| Description_DES | APR 22-24 VW MK8 Golf R 2.0T Stage 3+ PowerMax + Port Injection Turbo System |
| Description_EXT | Proven 3.12s 0-60 MPH - 9.55s 60-130 MPH - 11.16s 1/4 Mile at 3,000 DA, 10s Capable at Sea Level - For 2022+ VW Golf R and Audi S3 |
| Description_MKT | The APR Stage 3 System for the 2022+ Volkswagen Golf R and Audi S3 is the ultimate evolution of the EA888 Gen 4 platform - combining Garrett PowerMax GT2563S turbocharger support, APR's Multi-Port Injection fueling, and APR's Stage 3 ECU/TCU calibration into one factory-ECU-controlled ecosystem. The integrated MPI system works alongside the factory direct injection system under full ECU control, delivering the fuel capacity needed for true Stage 3+ power without a standalone controller. Available in 350 WTQ and 400 WTQ configurations with support for 91, 93, 100, 104 octane, and E85, the system has been validated at 3.12 seconds 0-60 MPH, an 11.16-second quarter mile at 123 MPH in full street trim at 3,000 density altitude - with 10-second capability at sea level - and 9.55 seconds 60-130 MPH, all while retaining OEM-style cold starts, drivability, and factory safety strategies. |
| Description_FAB | Complete Stage 3 ecosystem: ECU calibration, TCU calibration, and MPI fueling Compatible with Garrett PowerMax GT2563S turbocharger Bosch Motorsport high-flow, ethanol-compatible MPI injectors Available 350 WTQ and 400 WTQ output calibrations Supports 91, 93, 100, 104 octane, and E85 fuel calibrations APR Fuel Pressure Protection monitoring and safeguard strategies Proprietary launch control torque management for MQB EVO AWD traction Factory ECU controlled - no standalone engine management required Validated 3.12s 0-60 MPH; 11.16s quarter mile @ 123 MPH at 3,000 DA - 10-second capable at sea level Demonstrated 9.55s 60-130 MPH acceleration OEM-style cold starts, idle quality, and factory diagnostics retained Free Software Included for existing APR customers upgrading to APR Stage 3 ECU/TCU from lower stage (1/2) Plug-and-play with stock downpipe (emissions compliant) Upgraded Intake & Intercooler required, Gains shown using APR hardware. |
| Description_APS | 2022-2024 Volkswagen Golf R and Audi S3, 2.0T EA888 Gen 4, AWD (Haldex), 7-speed DQ381 DSG only - no manual transmission offered. Requires APR Intake and Intercooler for advertised performance. |
| Description_INS | Specific matching Stage 3+ software is REQUIRED to use this system (ECU + TCU). Software is included for existing APR customers upgrading to APR Stage 3 ECU/TCU from lower stage (1/2). Please check software compatibility prior to purchase or installation. APR Intake and Intercooler required for advertised performance (Gains shown using APR Hardware). Professional installation by an APR dealer strongly recommended. |
This Part Fits:
| Year | Make | Model | Submodel | Notes |
|---|---|---|---|---|
| 2022 | Audi | S3 | ||
| 2023 | Audi | S3 | ||
| 2024 | Audi | S3 | ||
| 2022 | Volkswagen | Arteon | ||
| 2023 | Volkswagen | Arteon | ||
| 2022 | Volkswagen | Golf R | ||
| 2023 | Volkswagen | Golf R | ||
| 2024 | Volkswagen | Golf R |
