Bilstein SNS2 Series - Suspension Shock Absorber 33-304175
Specifications:
| PartType | Shocks / Struts |
| Segment | Motorsports |
| Body Material | Steel |
| Piston Type | 3 (comp/reb) |
| Internal Design | Monotube |
| Collapsed Length (IN) | 15.12 |
| Extended Length (MM) | 607.0 |
| Lower Mount Type | 1/2in Heim |
| Collapsed Length (MM) | 384.0 |
| Body Design | Smooth Body Screw Top (Non-coilover) |
| Title | Bilstein Shock Absorbers |
| Prop 65 (Y/N) | Y |
| Boot Included | No |
| Extended Length (IN) | 23.90 |
| Body Diameter (ID) | 46mm |
| Upper Mount Type | 1/2in Heim |
| Spring Hardware | B4-BOA-0000117 |
| Adjustable Damping | Non-Adjustable |
| Series | SNS2 Series |
| Spring Seat Included | No |
| Finish | Zinc Plated |
| Prop 65 - Short Label | WARNING: Cancer & Reproductive Harm - www.P65Warnings.ca.gov |
| Description_FAB | 46mm piston design for maximum damping control |
| Description_FAB | 46mm piston design for maximum damping control |
| Description_FAB | Plated steel body for durability and superior heat dissipation |
| Description_SHO | Shock |
| Description_INV | SNS2, 9" Non Adj. Lin. C3-R3 |
| Description_DEF | Suspension Shock Absorber |
| Description_LAB | SNS2 Series - Suspension Shock Absorber |
| Description_DES | SNS2 Series - Suspension Shock Absorber |
| Description_ASM | No Applications |
| Description_EXT | 46mm Monotube Shock Absorber |
| Description_MKT | Bilstein SNS2 Series shock absorbers feature a steel, smooth body design utilizing the 46mm monotube technology (piston and piston band sold separately) designed for motorsports applications. These shock absorbers feature a steel body cap and a Schrader valve or fill plug. They are upgradeable to adjustable shafts and can be converted to a coilover (kit sold separately). SNS2 Series shock absorbers are ideal for racers whose sanctioning rules require an all steel construction with rebuild capability. |
