Holley EFI Holley Terminator X Fuel Injector - Individual 522-361S
Specifications:
| Body Diameter | 0.65 |
| Body Length | 1.85" |
| Body Style | EV6 |
| Brand | Holley Sniper EFI |
| Category | Air and Fuel Delivery |
| Connector Series | EV6 |
| Emission Code | 4 |
| Flow Rate | 36 |
| Fuel Type | E-85, Gasoline |
| 353 | Yes |
| 3390 | Performance |
| Impedance | High (12.2 Ohm) |
| O-Ring to O-Ring | 1.421 |
| part type | Fuel Injector |
| Product Type | Fuel Injector |
| Rated Injector Flow | 36 lb/hr |
| Sub Category | Fuel Injection System and Related Components |
| 44 | Male |
| 42 | 1 |
| 29 | Blade |
| Warning | California Proposition 65 |
| 488 | No |
| Description_INV | KIT- FUEL INJECTOR 36 PPH, SINGLE PACK |
| Description_ASC | These injectors are intended to be used with the 300-260 intake manifold. They are NOT a service injector for the Sniper EFI TBI Product Line. |
| Description_ASC | Designed for use in setups with a 38mm distance between the o-ring seats on the fuel rail and intake manifold (commonly referred to as an "LS3-Style" injector), this injector features a USCAR connector and 14mm o-rings on both ends. It is an ideal fit for Holley EFI Intake manifolds that include fuel rail brackets for shorter LS3/LS7 length injectors. However, when used in an intake manifold designed for factory LS3/LS7 injectors, the bottom o-ring needs to be replaced to ensure proper fitment. |
| Description_DES | Holley Terminator X Fuel Injector - Individual |
| Description_EXT | PICO/EV6 - 36 lb/hr - High Impedance |
| Description_MKT | Sniper EFI Fuel Injectors feature a precision lapped disc valve, high-quality brass windings, and high-temp O-rings. These injectors provide excellent linearity with no discernible "bounce" at low pulse widths as commonly found in other injectors. |
| Description_FAB | PICO/EV6 style performance injector |
| Description_FAB | High impedance (12.2 Ohms) for use with saturated drivers |
| Description_FAB | Rated injector flow: 36 lb/hr @ 43 PSI |
| Description_FAB | Supports up to 575 horsepower (set of 8) |
| Description_FAB | Tri-cone spray pattern |
