Holley's patent-pending HydraMat solves the fuel starvation problems associated with traditional pick-ups in stock fuel tanks and racing fuel cells. Surface tension and fluid wicking let it draw fuel from nearly any area of the mat that stays in contact with fuel, storing it in an internal reservoir so the engine keeps getting fuel during hard cornering, acceleration, stopping, inclines, and low fuel conditions.
Specifications:
- Category: Air and Fuel Delivery
- Product Type: HydraMats
- Length: 15 inches
- Width: 15 inches
- Micron Rating: 15
- Outlet: Center, 3/8" NPT
- Color: Beige
- Warranty: Manufacturer's Limited 90 Day Warranty
- Part Number: 16-100
Fits flat-bottom rectangular fuel cells with minimum dimensions of 15" x 15" in a cross shape. The female NPT thread does not require sealing paste or tape — using either could result in fuel pump failure. Works with alcohol, ethanol, methanol, and E-85 fuels, and 2-cycle oil blends up to 20:1; not for use with most other oils or diesel fuel.
FAQ
What size tank does this HydraMat fit?
It's designed for flat-bottom fuel cells with minimum dimensions of 15 inches by 15 inches, in a cross shape.
Does the NPT fitting need sealing tape or paste?
No — the female NPT thread does not require sealing paste or tape, and using either could cause fuel pump failure.
Can it be used with E-85 fuel?
Yes, it works with alcohol, ethanol, methanol, and E-85 fuels, and 2-cycle oil blends up to 20:1. It is not for use with most other oils or diesel fuel.
