Holley's patent-pending HydraMat solves the fuel starvation problems associated with traditional pick-ups in stock fuel tanks and racing fuel cells. Surface tension and fluid wicking let it draw fuel from nearly any area of the mat that stays in contact with fuel, storing it in an internal reservoir so the engine keeps getting fuel during hard cornering, acceleration, stopping, inclines, and low fuel conditions.
Specifications:
- Category: Air and Fuel Delivery
- Product Type: HydraMats
- Length: 11 inches
- Width: 11 inches
- Micron Rating: 15
- Outlet: Center, 3/8" NPT
- Color: Beige
- Warranty: Manufacturer's Limited 90 Day Warranty
- Part Number: 16-104
Fits flat-bottom rectangular fuel cells with minimum dimensions of 11" x 11" in a cross shape. The female NPT thread does not require sealing paste or tape — using either could result in fuel pump failure. For fixed in-tank stud mounting, Click Bond stud kits (available from aircraft supply retailers such as Aircraft Spruce) are recommended.
FAQ
What size tank does this HydraMat fit?
It's designed for flat-bottom fuel cells with minimum dimensions of 11 inches by 11 inches, in a cross shape.
Does the NPT fitting need sealing tape or paste?
No — the female NPT thread does not require sealing paste or tape, and using either could cause fuel pump failure.
What outlet fitting does it use?
It has a center outlet pick-up with a 3/8" NPT fitting.
