The Derale 15717 engine oil filter relocation kit moves the oil filter to an easier-to-reach location for quicker, cleaner filter changes. It includes a die-cast aluminum single ports-up remote filter mount and a Type N spin-on adapter with an 18x1.5mm engine thread, connected by a 10-foot length of OEM-spec hose. The remote mount accepts a Fram PH8A or equivalent filter, and the relocation also adds a bit of oil capacity, making the kit useful for engine swaps and tight engine bays.
Specifications:
- Type: engine oil filter relocation kit
- Engine thread: 18x1.5mm (Type N spin-on adapter)
- Ports: 1/2" NPT (adapter and remote mount inlets)
- Filter thread: 3/4"-16 (Fram PH8A or equivalent)
- Remote filter landing: 2-1/2" and 2-3/4"
- Hose: 1/2", 10 ft, OEM spec
- Material: die-cast aluminum
- Included: ports-up filter mount, spin-on adapter, hose
- Part number: 15717
FAQ
What does the Derale 15717 kit do?
It relocates the engine oil filter to a more accessible spot using a spin-on adapter, a remote filter mount, and connecting hose.
What engine thread does it use?
The Type N spin-on adapter uses an 18x1.5mm engine thread.
What filter fits the remote mount?
The mount uses a 3/4"-16 thread and accepts a Fram PH8A or equivalent filter.
How long is the hose?
The kit includes 10 feet of 1/2" OEM-spec hose.
