The Derale 10 inch Tornado Electric Puller Fan is one of the most popular fans in the Tornado line. The reversible fan uses six patented skewed blades to move 650 CFM at zero static pressure while drawing just 5.3 amps and running quietly. It can mount as a puller behind the radiator or be reversed to work as a pusher. This version includes the standard nylon mounting kit and illustrated installation instructions.
Specifications:
- Type: Tornado electric cooling fan
- Diameter: 10"
- Airflow: 650 CFM at 0 static pressure
- Amp draw: 5.3 amps
- Configuration: Puller, reversible (can be used as a pusher)
- Blades: Six patented skewed blades, quiet design
- Overall dimensions (W x H x D): 11-7/16" x 10-7/8" x 2-1/2" (blade depth 1-5/16")
- Mounting: 9-7/8" x 6-7/8"
- Includes: Standard nylon mounting kit and instructions
- Part number: 16620
FAQ
How much air does the Derale 16620 fan move?
It moves 650 CFM at zero static pressure and draws 5.3 amps.
Can it be used as a pusher or puller?
It is reversible, so it can mount as a puller behind the radiator or a pusher in front of it.
What is included?
It comes with the standard nylon mounting kit and illustrated installation instructions.
How deep is the fan?
It has an overall depth of 2-1/2 inches, with a 1-5/16 inch blade depth, which suits tight spaces.
