This CVF Racing V-belt pulley and bracket system runs a Saginaw P series power steering pump and an alternator on a Small Block Chevy (283, 302, 305, 350 and 400 CID) with a long water pump. The power steering pump mounts low on the driver side and the alternator sits on the passenger side in a mid-mount position.
All brackets and pulleys come in a Stealth Black finish. The pump, alternator, water pump and belts are purchased separately.
Specifications:
- Engine: Small Block Chevy 283, 302, 305, 350 and 400 CID
- Belt type: V-belt
- Water pump: Long Water Pump
- Power steering: Saginaw P series pump, low driver-side mount
- Alternator position: Mid-Mount, passenger side
- Air conditioning: None
- Finish: Stealth Black
- Part number: B-350-PS-SYSTEM-C-LWP
Kit Includes:
- 2-groove water pump pulley
- 2-groove crankshaft pulley
- 1-groove alternator pulley
- Passenger-side alternator bracket
- Driver-side power steering bracket
- Keyway-style power steering pulley
- Universal alternator fan (ALTFAN)
Not Included: Belts, power steering pump, alternator and water pump.
Application Notes:
- Uses a standard Chevy long water pump.
- Cylinder head type (standard, or Fuelie/camel hump heads without front bolt holes) and crank trigger (No, or Yes, which CVF says is usually reserved for race applications) are selected when ordering.
- Alternator, Saginaw power steering pump, water pump, power steering line kit and thermostat housing add-ons are sold separately.
Prop 65 Warning: This product can expose you to chemicals known to the State of California to cause cancer and reproductive harm. For more information visit www.P65Warnings.ca.gov.
FAQ
What engines does CVF Racing B-350-PS-SYSTEM-C-LWP fit?
CVF lists it for Small Block Chevy 283, 302, 305, 350 and 400 CID engines with a long water pump.
Which power steering pump does B-350-PS-SYSTEM-C-LWP use?
It is built around a Saginaw P series power steering pump mounted low on the driver side, using the included keyway-style pulley.
Is the power steering pump included with B-350-PS-SYSTEM-C-LWP?
No. Belts, the power steering pump, the alternator and the water pump are not included.
Where is the alternator mounted on B-350-PS-SYSTEM-C-LWP?
The alternator mounts on the passenger side of the engine in a mid-mount position.
