This polished CVF Racing bracket mounts a Saginaw power steering pump on the driver's side of a Ford 429 or 460 big block that runs an electric water pump. It is set up for V-belt pulleys and is meant to be used with CVF's SBC4PS power steering pulley.
CVF lists compatibility with Moroso, Meziere, CSR, ProForm and CVR electric water pumps, including Meziere Enterprises WP108, WP208 and WP308 series, Moroso 63595, CVR 8560 series and PRW electric water pumps.
Specifications:
- Bracket type: Power steering bracket, electric water pump
- Pump type: Saginaw
- Mounting position: Driver's side
- Water pump type: Electric
- Power steering pulley: For use with SBC4PS
- Belt type: V-belt
- Finish: Polished
- Engine: Ford 429 and 460 big block
- Part number: 460-PSBRKT-EWP
Not Included: The power steering pump, SBC4PS pulley and electric water pump are not included.
Application Notes:
- For the complete setup in CVF's engine photo, CVF lists 460-ALTBRKT-EWP, BBF1ALT, BBFL2CR and ALTFAN, each sold separately.
Additional Application Note: CVF lists this bracket by engine only (Ford 429 and 460 big block) and does not name specific vehicles.
Prop 65 Warning: This product can expose you to chemicals known to the State of California to cause cancer and reproductive harm. For more information visit www.P65Warnings.ca.gov.
FAQ
Which power steering pulley is used with this bracket?
CVF specifies its SBC4PS power steering pulley for this bracket, sold separately.
Which electric water pumps is it compatible with?
CVF lists Meziere Enterprises WP108, WP208 and WP308 series, Moroso 63595, CVR 8560 series and PRW electric water pumps, along with CSR and ProForm pumps.
What else completes the setup?
CVF pairs it with the 460-ALTBRKT-EWP alternator bracket, BBF1ALT alternator pulley, BBFL2CR crank pulley and ALTFAN, each sold separately.
Is there another finish?
Yes. CVF offers it in stealth black as part number B-460-PSBRKT-EWP.
