This CVF Racing alternator pulley has two V-belt grooves and a matching cover, machined from billet aluminum and polished. It fits Ford alternators with a 0.67" shaft, and the cap bolts are included.
The grooves are spaced 0.6" apart so they line up with CVF BBFE and SBFE series pulleys.
Specifications:
- Finish: Polished
- Material: Billet aluminum
- Belt type: V-belt
- Diameter: 3.2"
- Overall length: 2.7" (including cap)
- Grooves: 2
- Groove spacing: 0.6"
- Shaft diameter: 0.67"
- Part number: SBF2ALT
Kit Includes:
- Alternator pulley
- Pulley cap
- Cap bolts
Application Notes:
- Groove spacing matches CVF BBFE and SBFE series pulleys.
FAQ
What pulleys does the SBF2ALT line up with?
Its 0.6" groove spacing matches CVF BBFE and SBFE series pulleys.
Does it include the cap?
Yes. The pulley comes with its matching cap and cap bolts.
What size is the SBF2ALT?
It is 3.2" in diameter and 2.7" long including the cap, with two grooves and a 0.67" shaft bore.
