This CVF Racing mechanical water pump is a high-flow aluminum pump with a black finish for Ford small block 289, 302 and 351 Windsor engines. It runs standard clockwise rotation with the lower radiator hose connection on the driver side.
It is intended for restorations, swaps and performance builds using properly configured factory-style brackets or CVF Racing serpentine systems.
Specifications:
- Engine: Ford 289, 302 and 351W
- Pump type: Mechanical, high-flow
- Rotation: Standard (clockwise)
- Hub height: 5-3/4 in.
- Pilot shaft diameter: 5/8 in.
- Inlet diameter: 1-3/4 in.
- Lower radiator hose connection: Driver side
- Material: Aluminum
- Finish: Black
- Reference numbers (not verified as exact interchanges): Ford Performance M-8501-F351, Ford Racing M-8501-D351S
- Warranty: CVF Racing Lifetime Warranty
- Part number: B-SBFL-WP
Prop 65 Warning: This product can expose you to chemicals known to the State of California to cause cancer and reproductive harm. For more information visit www.P65Warnings.ca.gov.
FAQ
What engines does this pump fit?
It is built for Ford small block 289, 302 and 351 Windsor engines with a driver-side lower radiator hose layout.
What rotation and hub height does it have?
It is a standard clockwise pump with a 5-3/4 in. hub height and a 5/8 in. pilot shaft diameter.
Which side is the lower hose connection on?
The lower radiator hose connects on the driver side through a 1-3/4 in. inlet.
Is another finish available?
Yes. CVF also offers this pump as SBFL-WP in a natural satin cast finish.
