The CSF 3054 is an all-aluminum high-performance radiator for the 1988-1991 BMW E30 325i and the 1992-1999 E36 3-Series and M3 with manual transmissions. It uses a 2-row 42mm dual core with CSF's B-Tube Technology and multi-louvered 6.5mm fins for high heat rejection. It is a drop-in fit with CNC-machined quick-connect connections and brackets, an all-aluminum race-style drain plug, and a satin finish, and it accepts the OEM hoses, AC condenser, brackets, and fan shroud.
- Type: all-aluminum performance radiator
- Core: 2-row, 42mm dual core, B-Tube Technology
- Fins: multi-louvered, 6.5mm fin height
- Fittings: CNC-machined quick-connect and brackets
- Drain: all-aluminum race-style drain plug
- Finish: satin
- Transmission: manual
- Fitment: drop-in, no modifications
- Part number: 3054
Vehicle Applications
Direct fit on the following (manual transmission):
- 1988 BMW 325i (E30)
- 1989 BMW 325i (E30)
- 1990 BMW 325i (E30)
- 1991 BMW 325i (E30)
- 1992 BMW 325i (E36)
- 1993 BMW 325i (E36)
- 1994 BMW 325i (E36)
- 1995 BMW 325i (E36)
- 1998 BMW 323i (E36)
- 1999 BMW 323i (E36)
- 1996 BMW 328i (E36)
- 1997 BMW 328i (E36)
- 1998 BMW 328i (E36)
- 1999 BMW 328i (E36)
- 1995 BMW M3 (E36)
- 1996 BMW M3 (E36)
- 1997 BMW M3 (E36)
- 1998 BMW M3 (E36)
- 1999 BMW M3 (E36)
FAQ
What vehicles does the CSF 3054 fit?
The 1988-1991 BMW E30 325i (including is and ix) and the 1992-1999 E36 3-Series (323i, 325i, 328i) and M3, with manual transmissions.
Does it fit an E30?
Yes. It fits the 1988-1991 E30 325i, 325is, and 325ix.
Is it a drop-in fit?
Yes. It accepts the OEM hoses, brackets, AC condenser, and fan shroud with no modifications.
How many rows is the core?
A 2-row 42mm dual core with CSF's B-Tube Technology.
