MSD Cadillac V8 Distributor w/Vacuum Advance 8363
Specifications:
| Brand | MSD |
| C.A.R.B. EO # | D-40-39 |
| Color | Red |
| 9047 | Yes |
| Distributor Type | Magnetic Pickup |
| Emission Code | 1 |
| Gear Material | Steel Melonized QPQ Coated |
| 3390 | Performance |
| 5626 | Yes |
| 6783 | No |
| 9048 | Yes |
| Product Type | Distributor |
| Warning | California Proposition 65 |
| part type | Distributor |
| Category | Ignition |
| Sub Category | Distributor and Magneto |
| Warranty | Manufacturer's Limited 1 Year Warranty |
| Brand | MSD |
| C.A.R.B. EO # | D-40-39 |
| Color | Red |
| 9047 | Yes |
| Distributor Type | Magnetic Pickup |
| Emission Code | 1 |
| Gear Material | Steel Melonized QPQ Coated |
| 3390 | Performance |
| 5626 | Yes |
| 6783 | No |
| 9048 | Yes |
| Product Type | Distributor |
| Warning | California Proposition 65 |
| part type | Distributor |
| Category | Ignition |
| Sub Category | Distributor and Magneto |
| Warranty | Manufacturer's Limited 1 Year Warranty |
| Description_SHO | V8 Distributor |
| Description_INV | Distributor,Cadillac V8 w/Vacuum Advance |
| Description_DES | Cadillac V8 Distributor w/Vacuum Advance |
| Description_EXT | Fits 368, 425, 472 and 500 Cadillac V8. Must be used with an MSD 6, 7 or 8-series ignition. Includes vacuum advance. |
| Description_MKT | Cadillac cruisers will be excited about this new Pro-Billet distributor for the 368, 425, 472 and 500 cubic inch engines. |
| Description_MKT | The Distributor begins life as a billet of 6061-T6 aluminum before being CNC-machined to precise dimensions. The sturdy, flex-free housing is fitted with a sealed ball-bearing and long sintered bushing for high-rpm accuracy. |
| Description_MKT | MSD's race proven magnetic pickup supplies a trigger signal that is accurate to within one degree at any rpm. Mounted above this pickup is an adjustable mechanical advance and is supplied with different springs and stop bushings for a number of curves. For street cruising economy, as if there's any such thing in a Caddy, there is a vacuum advance canister. |
| Description_FAB | Special oil tract improves lubrication to the distributor and cam gear |
| Description_FAB | Supplied with an HEI style distributor cap and rotor (accepts Cap-A-Dapts) |
| Description_FAB | CNC machined billet aluminum housing and billet aluminum base |
| Description_FAB | Mechanical advance assembly can be locked out for crank trigger systems |
| Description_FAB | Vacuum advance canister for improved economy (can be locked out) |
| Description_FAB | CARB E.O. Approved |
| Description_FAB | Polished steel shaft is QPQ coated and guided by a sealed ball bearing |
| Description_FAB | Maintenance-free magnetic pickup and precision reluctor create stable trigger signals throughout the rpm range |
| Description_FAB | Must be used with an MSD Ignition Control |
| Description_FAB | Designed for Cadillac 368, 425, 472 and 500 ci engines |
| Description_FAB | Easy-to-adjust mechanical advance with supplied springs and stop bushings |
| Description_SHO | V8 Distributor |
| Description_INV | Distributor,Cadillac V8 w/Vacuum Advance |
| Description_DES | Cadillac V8 Distributor w/Vacuum Advance |
| Description_EXT | Fits 368, 425, 472 and 500 Cadillac V8. Must be used with an MSD 6, 7 or 8-series ignition. Includes vacuum advance. |
| Description_MKT | Cadillac cruisers will be excited about this new Pro-Billet distributor for the 368, 425, 472 and 500 cubic inch engines. |
| Description_MKT | The Distributor begins life as a billet of 6061-T6 aluminum before being CNC-machined to precise dimensions. The sturdy, flex-free housing is fitted with a sealed ball-bearing and long sintered bushing for high-rpm accuracy. |
| Description_MKT | MSD's race proven magnetic pickup supplies a trigger signal that is accurate to within one degree at any rpm. Mounted above this pickup is an adjustable mechanical advance and is supplied with different springs and stop bushings for a number of curves. For street cruising economy, as if there's any such thing in a Caddy, there is a vacuum advance canister. |
| Description_FAB | Special oil tract improves lubrication to the distributor and cam gear |
| Description_FAB | Supplied with an HEI style distributor cap and rotor (accepts Cap-A-Dapts) |
| Description_FAB | CNC machined billet aluminum housing and billet aluminum base |
| Description_FAB | Mechanical advance assembly can be locked out for crank trigger systems |
| Description_FAB | Vacuum advance canister for improved economy (can be locked out) |
| Description_FAB | CARB E.O. Approved |
| Description_FAB | Polished steel shaft is QPQ coated and guided by a sealed ball bearing |
| Description_FAB | Maintenance-free magnetic pickup and precision reluctor create stable trigger signals throughout the rpm range |
| Description_FAB | Must be used with an MSD Ignition Control |
| Description_FAB | Designed for Cadillac 368, 425, 472 and 500 ci engines |
| Description_FAB | Easy-to-adjust mechanical advance with supplied springs and stop bushings |
This Part Fits:
| Year | Make | Model | Submodel | Notes |
|---|---|---|---|---|
| 1965 | Cadillac | Calais | Base | |
| 1966 | Cadillac | Calais | Base | |
| 1967 | Cadillac | Calais | Base | |
| 1968 | Cadillac | Calais | Base | |
| 1969 | Cadillac | Calais | Base | |
| 1970 | Cadillac | Calais | Base | |
| 1971 | Cadillac | Calais | Base | |
| 1972 | Cadillac | Calais | Base | |
| 1973 | Cadillac | Calais | Base | |
| 1974 | Cadillac | Calais | Base | |
| 1975 | Cadillac | Calais | Base | |
| 1976 | Cadillac | Calais | Base | |
| 1964 | Cadillac | DeVille | Base | |
| 1965 | Cadillac | DeVille | Base | |
| 1966 | Cadillac | DeVille | Base | |
| 1967 | Cadillac | DeVille | Base | |
| 1968 | Cadillac | DeVille | Base | |
| 1969 | Cadillac | DeVille | Base | |
| 1970 | Cadillac | DeVille | Base | |
| 1971 | Cadillac | DeVille | Base | |
| 1972 | Cadillac | DeVille | Base | |
| 1973 | Cadillac | DeVille | Base | |
| 1974 | Cadillac | DeVille | Base | |
| 1975 | Cadillac | DeVille | Base | |
| 1976 | Cadillac | DeVille | Base | |
| 1977 | Cadillac | DeVille | Base | |
| 1978 | Cadillac | DeVille | Base | |
| 1979 | Cadillac | DeVille | Base | |
| 1980 | Cadillac | DeVille | Base | |
| 1981 | Cadillac | DeVille | Base | |
| 1975 | Cadillac | DeVille | Cabriolet | |
| 1976 | Cadillac | DeVille | Cabriolet | |
| 1978 | Cadillac | DeVille | Cabriolet | |
| 1979 | Cadillac | DeVille | Cabriolet | |
| 1980 | Cadillac | DeVille | Cabriolet | |
| 1981 | Cadillac | DeVille | Cabriolet | |
| 1975 | Cadillac | DeVille | d'Elegance | |
| 1976 | Cadillac | DeVille | d'Elegance | |
| 1977 | Cadillac | DeVille | d'Elegance | |
| 1978 | Cadillac | DeVille | d'Elegance | |
| 1979 | Cadillac | DeVille | d'Elegance | |
| 1980 | Cadillac | DeVille | d'Elegance | |
| 1981 | Cadillac | DeVille | d'Elegance | |
| 1978 | Cadillac | DeVille | Phaeton | |
| 1979 | Cadillac | DeVille | Phaeton | |
| 1964 | Cadillac | Eldorado | Base | |
| 1965 | Cadillac | Eldorado | Base | |
| 1966 | Cadillac | Eldorado | Base | |
| 1967 | Cadillac | Eldorado | Base | |
| 1968 | Cadillac | Eldorado | Base | |
| 1969 | Cadillac | Eldorado | Base | |
| 1970 | Cadillac | Eldorado | Base | |
| 1971 | Cadillac | Eldorado | Base | |
| 1972 | Cadillac | Eldorado | Base | |
| 1973 | Cadillac | Eldorado | Base | |
| 1974 | Cadillac | Eldorado | Base | |
| 1975 | Cadillac | Eldorado | Base | |
| 1976 | Cadillac | Eldorado | Base | |
| 1977 | Cadillac | Eldorado | Base | |
| 1978 | Cadillac | Eldorado | Base | |
| 1980 | Cadillac | Eldorado | Base | |
| 1981 | Cadillac | Eldorado | Base | |
| 1964 | Cadillac | Eldorado | Biarritz | |
| 1976 | Cadillac | Eldorado | Biarritz | |
| 1977 | Cadillac | Eldorado | Biarritz | |
| 1978 | Cadillac | Eldorado | Biarritz | |
| 1980 | Cadillac | Eldorado | Biarritz | |
| 1981 | Cadillac | Eldorado | Biarritz | |
| 1976 | Cadillac | Eldorado | Bicentenial Edition | |
| 1981 | Cadillac | Eldorado | Brougham d'Elegance | |
| 1976 | Cadillac | Eldorado | Cabriolet | |
| 1978 | Cadillac | Eldorado | Cabriolet | |
| 1980 | Cadillac | Eldorado | Cabriolet | |
| 1981 | Cadillac | Eldorado | Cabriolet | |
| 1965 | Cadillac | Fleetwood | 60 Special | |
| 1966 | Cadillac | Fleetwood | 60 Special | |
| 1967 | Cadillac | Fleetwood | 60 Special | |
| 1969 | Cadillac | Fleetwood | 60 Special | |
| 1970 | Cadillac | Fleetwood | 60 Special | |
| 1971 | Cadillac | Fleetwood | 60 Special | |
| 1972 | Cadillac | Fleetwood | 60 Special | |
| 1973 | Cadillac | Fleetwood | 60 Special | |
| 1974 | Cadillac | Fleetwood | 60 Special | |
| 1973 | Cadillac | Fleetwood | 60 Special Brougham | |
| 1974 | Cadillac | Fleetwood | 60 Special Brougham | |
| 1975 | Cadillac | Fleetwood | 60 Special Brougham | |
| 1976 | Cadillac | Fleetwood | 60 Special Brougham | |
| 1965 | Cadillac | Fleetwood | 75 | |
| 1966 | Cadillac | Fleetwood | 75 | |
| 1967 | Cadillac | Fleetwood | 75 | |
| 1968 | Cadillac | Fleetwood | 75 | |
| 1969 | Cadillac | Fleetwood | 75 | |
| 1970 | Cadillac | Fleetwood | 75 | |
| 1971 | Cadillac | Fleetwood | 75 | |
| 1972 | Cadillac | Fleetwood | 75 | |
| 1973 | Cadillac | Fleetwood | 75 | |
| 1974 | Cadillac | Fleetwood | 75 | |
| 1975 | Cadillac | Fleetwood | 75 | |
| 1976 | Cadillac | Fleetwood | 75 | |
| 1977 | Cadillac | Fleetwood | 75 | |
| 1977 | Cadillac | Fleetwood | 75 Formal | |
| 1978 | Cadillac | Fleetwood | Base | |
| 1979 | Cadillac | Fleetwood | Base | |
| 1980 | Cadillac | Fleetwood | Base | |
| 1981 | Cadillac | Fleetwood | Base | |
| 1982 | Cadillac | Fleetwood | Base | |
| 1983 | Cadillac | Fleetwood | Base | |
| 1984 | Cadillac | Fleetwood | Base | |
| 1969 | Cadillac | Fleetwood | Brougham | |
| 1970 | Cadillac | Fleetwood | Brougham | |
| 1976 | Cadillac | Fleetwood | Brougham | |
| 1977 | Cadillac | Fleetwood | Brougham | |
| 1978 | Cadillac | Fleetwood | Brougham | |
| 1979 | Cadillac | Fleetwood | Brougham | |
| 1980 | Cadillac | Fleetwood | Brougham | |
| 1981 | Cadillac | Fleetwood | Brougham | |
| 1976 | Cadillac | Fleetwood | Brougham d'Elegance | |
| 1978 | Cadillac | Fleetwood | Brougham d'Elegance | |
| 1979 | Cadillac | Fleetwood | Brougham d'Elegance | |
| 1980 | Cadillac | Fleetwood | Brougham d'Elegance | |
| 1981 | Cadillac | Fleetwood | Brougham d'Elegance | |
| 1976 | Cadillac | Fleetwood | Brougham Talisman | |
| 1977 | Cadillac | Fleetwood | Formal | |
| 1978 | Cadillac | Fleetwood | Formal | |
| 1979 | Cadillac | Fleetwood | Formal | |
| 1980 | Cadillac | Fleetwood | Formal | |
| 1981 | Cadillac | Fleetwood | Formal | |
| 1982 | Cadillac | Fleetwood | Formal | |
| 1983 | Cadillac | Fleetwood | Formal | |
| 1984 | Cadillac | Fleetwood | Formal | |
| 1964 | Cadillac | Series 60 Fleetwood | Base | |
| 1964 | Cadillac | Series 62 | Base | |
| 1964 | Cadillac | Series 75 Fleetwood | Base | |
| 1980 | Cadillac | Seville | Base | |
| 1981 | Cadillac | Seville | Base | |
| 1980 | Cadillac | Seville | Elegante | |
| 1981 | Cadillac | Seville | Elegante |
