Allstar Performance medium head flange-type rivets in silver aluminum, sold in a box of 250. These tri-fold rivets have a perforated body that opens and expands on the backside to create a larger bearing surface, eliminating the need for backer washers.
Each rivet has a 3/8 inch head, a steel mandrel measuring 3/16 inch, and a grip range of 1/16 inch to 1/2 inch. The rivet body is aluminum with a natural finish. Allstar Performance recommends a 13/64 inch drill bit for best results.
Allstar Performance Spec Sheet (PDF)
FAQ
What makes a flange-type rivet different from a standard rivet?
Flange-type (tri-fold) rivets have a perforated body that opens and expands on the backside when set, creating a wide bearing surface without needing a separate backer washer.
What drill bit size is recommended for this rivet?
Allstar Performance recommends a 13/64 inch drill bit for best results.
How many rivets are in this box?
This box contains 250 medium head flange-type rivets.
What is the grip range of ALL18185?
ALL18185 has a grip range of 1/16 inch to 1/2 inch.
What mandrel does this rivet use?
This rivet uses a 3/16 inch steel mandrel.
