AFR's Eliminator Race cylinder heads are fully assembled, aluminum Small Block Chevy heads built with 235cc intake runners and 70cc combustion chambers for serious race applications. They use an angle-plug design and ship as a matched pair ready to bolt on.
Specifications:
- Type: Eliminator Race
- Condition: Assembled
- Intake Valve: 2.100 in
- Exhaust Valve: 1.600 in
- Intake Runner Volume: 235 cc
- Combustion Chamber Volume: 70 cc
- Spring Diameter: 1.550 in
- Spark Plug Style: Angle Plug
- Material: Aluminum
- Quantity: Pair
- Part Number: 1134-TI
Applications:
- Small Block Chevy
FAQ
What engine platform does this cylinder head fit?
It's built for the Small Block Chevy platform.
Is this head assembled or bare?
It ships fully assembled, ready to install.
What size are the intake and exhaust valves?
2.100 in intake and 1.600 in exhaust valves.
What spark plug style does it use?
An angle-plug design.
How many heads come in this listing?
It's sold as a matched pair.
