The Derale 16110 is a 10-inch high output electric puller fan from the H.O. Extreme series, built around a sealed IP68 waterproof and dustproof motor for durability in harsh underhood conditions. Ten thin, curved blades move 825 CFM while keeping the overall profile slim, just 2-1/16 inches at its widest point, so it fits tight clearances behind a radiator or cooler. It is designed to pull air from the engine side and works as a primary or auxiliary cooling fan on a wide range of universal applications.
Specifications:
- Fan diameter: 10"
- Series: H.O. Extreme
- Airflow: 825 CFM
- Amp draw: 9.2 A
- Blade: 10 thin curved blades
- Orientation: puller only (engine side)
- Motor: sealed IP68 certified waterproof and dustproof
- Dimensions: 10-1/2" W x 11-1/8" H x 1-1/16" D (overall depth 2-1/16")
- Mounting pattern: 9" x 9"
- Included: mounting kit and illustrated installation instructions
- Part number: 16110
FAQ
What is the Derale 16110?
It is a 10-inch high output electric puller fan from the H.O. Extreme series, rated at 825 CFM and built with a sealed IP68 motor. It pulls air through a radiator or cooler from the engine side.
How much air does it move and what is the amp draw?
The fan is rated at 825 CFM with a 9.2 amp draw.
Is it a puller or pusher fan?
It is a puller fan only, mounted on the engine side of the radiator or cooler.
Does it include mounting hardware?
Yes. A mounting kit and illustrated installation instructions are included. The mounting pattern measures 9 inches by 9 inches.
Is the motor waterproof?
Yes. The 16110 uses a sealed IP68 certified motor that is both waterproof and dustproof.
