Edelbrock Engine Water Pump 88120
Specifications:
| Thermostat And Housing Included | No |
| Casting Number | 8812 |
| Impeller Rotation | Standard |
| Includes Back Housing | Yes |
| Mounting Hardware Included | No |
| Hub Hole Quantity | 6 |
| Housing Material | Aluminum |
| Water Pump Drive Type | V-Belt |
| Impeller Material | Powdered Metal |
| Related Cooling Fan Components | No |
| Installation Warnings | Yes |
| Outlet Quantity | 1 |
| RGL | WARNING: This product can expose you to Lead, which is known to the State of California to cause cancer or birth defects or other reproductive harm. For more information, visit www.P65warnings.ca.gov. |
| Fan Clutch Included | No |
| Mounting Hole Quantity | 4 |
| Impeller Vane Quantity | 6 |
| Pulley Included | No |
| Hub Height | 5.813 |
| Description_ABR | Water Pump |
| Description_INV | Water Pump Short Style 1971-82 Covette |
| Description_LAB | Water Pump for Small-Block 1971-82 Corvettes in Satin Finish (Short) |
| Description_ASM | Chevrolet:Small-Block Corvette:262 (4.3L)-400 (6.6L) |
| Description_EXT | Edelbrock #88120 water pump for all 1971-82 SBC Corvettes provides maximum cooling |
| Description_MKT | Edelbrock #88120 water pump for all 1971-82 SBC Corvettes provides maximum cooling form the street and the race track. Water pump provide maximum flow, maximum pressure and equal distribution to both sides of the block with 1%. |
| Description_TRA | 1969-'76 vehicles (original pump casting #3853692) require the included spacer to be placed between the pump and the alternator bracket |
| Description_TRA | Some applications (original pump casting #364790) require power steering bracket spacer (included) |
| Description_TRA | Some vehicles (original pump casting #6263701) require a through hole instead of the threaded hole for the power steering. If this is the case, drill out the threads with a 3/8" drill bit |
| Description_TRA | Check closely for any interference with drive belts |
| Description_TRA | some filing for clearance may be necessary with some applications |
| Description_TRA | Installation is the same as for original equipment water pumps. Consult service manual for specific procedures, if necessary |
| Description_TRA | CAUTION: Be sure that fan bolts don't protrude through the hub so far that they hit the water pump housing |
| Description_TRA | NOTE: Removal of backing plate is not recommended, as there are no user serviceable parts in the water pump. If backing plate is removed, use no sealer on O-ring equipped models, and use conventional gasket sealer (not RTV silicone) on gasketed models. |
| Description_DEF | Engine Water Pump |
This Part Fits:
| Year | Make | Model | Submodel | Notes |
|---|---|---|---|---|
| 1971 | Chevrolet | Corvette | Satin Finish; Short-Style; Standard Rotation; 3/4in. Pilot Shaft; 3/4in. Ball/Ball Bearing; 5 13/16in. Block To Hub Height; 1.80in. Inlet,Satin Finish; Short-Style; Standard Rotation; 3/4in. Pilot Shaft; 3/4in. Ball/Ball Bearing; 5 13/16in. Block To Hub Height; 1.80in. Inlet,Satin Finish; Short-Style; Standard Rotation; 3/4in. Pilot Shaft; 3/4in. Ball/Ball Bearing; 5 13/16in. Block To Hub Height; 1.80in. Inlet,Satin Finish; Short-Style; Standard Rotation; 3/4in. Pilot Shaft; 3/4in. Ball/Ball Bearing; 5 13/16in. Block To Hub Height; 1.80in. Inlet | |
| 1972 | Chevrolet | Corvette | Satin Finish; Short-Style; Standard Rotation; 3/4in. Pilot Shaft; 3/4in. Ball/Ball Bearing; 5 13/16in. Block To Hub Height; 1.80in. Inlet,Satin Finish; Short-Style; Standard Rotation; 3/4in. Pilot Shaft; 3/4in. Ball/Ball Bearing; 5 13/16in. Block To Hub Height; 1.80in. Inlet,Satin Finish; Short-Style; Standard Rotation; 3/4in. Pilot Shaft; 3/4in. Ball/Ball Bearing; 5 13/16in. Block To Hub Height; 1.80in. Inlet,Satin Finish; Short-Style; Standard Rotation; 3/4in. Pilot Shaft; 3/4in. Ball/Ball Bearing; 5 13/16in. Block To Hub Height; 1.80in. Inlet | |
| 1973 | Chevrolet | Corvette | Satin Finish; Short-Style; Standard Rotation; 3/4in. Pilot Shaft; 3/4in. Ball/Ball Bearing; 5 13/16in. Block To Hub Height; 1.80in. Inlet,Satin Finish; Short-Style; Standard Rotation; 3/4in. Pilot Shaft; 3/4in. Ball/Ball Bearing; 5 13/16in. Block To Hub Height; 1.80in. Inlet,Satin Finish; Short-Style; Standard Rotation; 3/4in. Pilot Shaft; 3/4in. Ball/Ball Bearing; 5 13/16in. Block To Hub Height; 1.80in. Inlet,Satin Finish; Short-Style; Standard Rotation; 3/4in. Pilot Shaft; 3/4in. Ball/Ball Bearing; 5 13/16in. Block To Hub Height; 1.80in. Inlet | |
| 1974 | Chevrolet | Corvette | Satin Finish; Short-Style; Standard Rotation; 3/4in. Pilot Shaft; 3/4in. Ball/Ball Bearing; 5 13/16in. Block To Hub Height; 1.80in. Inlet,Satin Finish; Short-Style; Standard Rotation; 3/4in. Pilot Shaft; 3/4in. Ball/Ball Bearing; 5 13/16in. Block To Hub Height; 1.80in. Inlet,Satin Finish; Short-Style; Standard Rotation; 3/4in. Pilot Shaft; 3/4in. Ball/Ball Bearing; 5 13/16in. Block To Hub Height; 1.80in. Inlet,Satin Finish; Short-Style; Standard Rotation; 3/4in. Pilot Shaft; 3/4in. Ball/Ball Bearing; 5 13/16in. Block To Hub Height; 1.80in. Inlet | |
| 1975 | Chevrolet | Corvette | Satin Finish; Short-Style; Standard Rotation; 3/4in. Pilot Shaft; 3/4in. Ball/Ball Bearing; 5 13/16in. Block To Hub Height; 1.80in. Inlet,Satin Finish; Short-Style; Standard Rotation; 3/4in. Pilot Shaft; 3/4in. Ball/Ball Bearing; 5 13/16in. Block To Hub Height; 1.80in. Inlet,Satin Finish; Short-Style; Standard Rotation; 3/4in. Pilot Shaft; 3/4in. Ball/Ball Bearing; 5 13/16in. Block To Hub Height; 1.80in. Inlet,Satin Finish; Short-Style; Standard Rotation; 3/4in. Pilot Shaft; 3/4in. Ball/Ball Bearing; 5 13/16in. Block To Hub Height; 1.80in. Inlet | |
| 1976 | Chevrolet | Corvette | Satin Finish; Short-Style; Standard Rotation; 3/4in. Pilot Shaft; 3/4in. Ball/Ball Bearing; 5 13/16in. Block To Hub Height; 1.80in. Inlet,Satin Finish; Short-Style; Standard Rotation; 3/4in. Pilot Shaft; 3/4in. Ball/Ball Bearing; 5 13/16in. Block To Hub Height; 1.80in. Inlet,Satin Finish; Short-Style; Standard Rotation; 3/4in. Pilot Shaft; 3/4in. Ball/Ball Bearing; 5 13/16in. Block To Hub Height; 1.80in. Inlet,Satin Finish; Short-Style; Standard Rotation; 3/4in. Pilot Shaft; 3/4in. Ball/Ball Bearing; 5 13/16in. Block To Hub Height; 1.80in. Inlet | |
| 1977 | Chevrolet | Corvette | Satin Finish; Short-Style; Standard Rotation; 3/4in. Pilot Shaft; 3/4in. Ball/Ball Bearing; 5 13/16in. Block To Hub Height; 1.80in. Inlet,Satin Finish; Short-Style; Standard Rotation; 3/4in. Pilot Shaft; 3/4in. Ball/Ball Bearing; 5 13/16in. Block To Hub Height; 1.80in. Inlet,Satin Finish; Short-Style; Standard Rotation; 3/4in. Pilot Shaft; 3/4in. Ball/Ball Bearing; 5 13/16in. Block To Hub Height; 1.80in. Inlet,Satin Finish; Short-Style; Standard Rotation; 3/4in. Pilot Shaft; 3/4in. Ball/Ball Bearing; 5 13/16in. Block To Hub Height; 1.80in. Inlet | |
| 1978 | Chevrolet | Corvette | Satin Finish; Short-Style; Standard Rotation; 3/4in. Pilot Shaft; 3/4in. Ball/Ball Bearing; 5 13/16in. Block To Hub Height; 1.80in. Inlet,Satin Finish; Short-Style; Standard Rotation; 3/4in. Pilot Shaft; 3/4in. Ball/Ball Bearing; 5 13/16in. Block To Hub Height; 1.80in. Inlet,Satin Finish; Short-Style; Standard Rotation; 3/4in. Pilot Shaft; 3/4in. Ball/Ball Bearing; 5 13/16in. Block To Hub Height; 1.80in. Inlet,Satin Finish; Short-Style; Standard Rotation; 3/4in. Pilot Shaft; 3/4in. Ball/Ball Bearing; 5 13/16in. Block To Hub Height; 1.80in. Inlet | |
| 1979 | Chevrolet | Corvette | Satin Finish; Short-Style; Standard Rotation; 3/4in. Pilot Shaft; 3/4in. Ball/Ball Bearing; 5 13/16in. Block To Hub Height; 1.80in. Inlet | |
| 1979 | Chevrolet | Corvette | Satin Finish; Short-Style; Standard Rotation; 3/4in. Pilot Shaft; 3/4in. Ball/Ball Bearing; 5 13/16in. Block To Hub Height; 1.80in. Inlet | |
| 1980 | Chevrolet | Corvette | Satin Finish; Short-Style; Standard Rotation; 3/4in. Pilot Shaft; 3/4in. Ball/Ball Bearing; 5 13/16in. Block To Hub Height; 1.80in. Inlet | |
| 1980 | Chevrolet | Corvette | Satin Finish; Short-Style; Standard Rotation; 3/4in. Pilot Shaft; 3/4in. Ball/Ball Bearing; 5 13/16in. Block To Hub Height; 1.80in. Inlet,Satin Finish; Short-Style; Standard Rotation; 3/4in. Pilot Shaft; 3/4in. Ball/Ball Bearing; 5 13/16in. Block To Hub Height; 1.80in. Inlet,Satin Finish; Short-Style; Standard Rotation; 3/4in. Pilot Shaft; 3/4in. Ball/Ball Bearing; 5 13/16in. Block To Hub Height; 1.80in. Inlet | |
| 1981 | Chevrolet | Corvette | Satin Finish; Short-Style; Standard Rotation; 3/4in. Pilot Shaft; 3/4in. Ball/Ball Bearing; 5 13/16in. Block To Hub Height; 1.80in. Inlet,Satin Finish; Short-Style; Standard Rotation; 3/4in. Pilot Shaft; 3/4in. Ball/Ball Bearing; 5 13/16in. Block To Hub Height; 1.80in. Inlet,Satin Finish; Short-Style; Standard Rotation; 3/4in. Pilot Shaft; 3/4in. Ball/Ball Bearing; 5 13/16in. Block To Hub Height; 1.80in. Inlet | |
| 1982 | Chevrolet | Corvette | Satin Finish; Short-Style; Standard Rotation; 3/4in. Pilot Shaft; 3/4in. Ball/Ball Bearing; 5 13/16in. Block To Hub Height; 1.80in. Inlet,Satin Finish; Short-Style; Standard Rotation; 3/4in. Pilot Shaft; 3/4in. Ball/Ball Bearing; 5 13/16in. Block To Hub Height; 1.80in. Inlet,Satin Finish; Short-Style; Standard Rotation; 3/4in. Pilot Shaft; 3/4in. Ball/Ball Bearing; 5 13/16in. Block To Hub Height; 1.80in. Inlet |
