Weiand Weiand Stealth Ram Intake - Chevy Small Block V8 7540
Specifications:
| Basic Operating RPM Range | 800-6500 |
| Brand | Weiand |
| Carburetor Flange | N/A |
| Carburetor Quantity | N/A |
| Carburetor Studs Included | N/A |
| Category | Engine |
| 9063 | No |
| 17 | Silver |
| 158 | Cast |
| 5337 | Rectangle |
| 6621 | 9.025 |
| 8095 | No |
| Emission Code | 4 |
| Engine | Chevrolet Small Block Gen I |
| Flange Style | N/A |
| 6643 | 10.25 |
| 906 | No |
| 10644 | No |
| Fuel System Type | EFI |
| 353 | No |
| 3390 | Performance |
| 10651 | No |
| Manifold Type | High Rise |
| 10 | Aluminum |
| 10648 | No |
| part type | Engine Intake Manifold |
| Plenum Finish | Cast |
| Product Type | Intake Manifold |
| 6645 | 10.25 |
| 10645 | No |
| 10649 | No |
| Single Or Dual Plane Type | Single |
| Sub Category | Cylinder Block Components |
| 10646 | 2.28 |
| Throttle Body Gasket Included | No |
| 10626 | No |
| Vacuum Ports | Yes |
| Warning | California Proposition 65 |
| Warranty | Manufacturer's Limited 90 Day Warranty |
| Basic Operating RPM Range | 800-6500 |
| Brand | Weiand |
| Carburetor Flange | N/A |
| Carburetor Quantity | N/A |
| Carburetor Studs Included | N/A |
| Category | Engine |
| 9063 | No |
| 17 | Silver |
| 158 | Cast |
| 5337 | Rectangle |
| 6621 | 9.025 |
| 8095 | No |
| Emission Code | 4 |
| Engine | Chevrolet Small Block Gen I |
| Flange Style | N/A |
| 6643 | 10.25 |
| 906 | No |
| 10644 | No |
| Fuel System Type | EFI |
| 353 | No |
| 3390 | Performance |
| 10651 | No |
| Manifold Type | High Rise |
| 10 | Aluminum |
| 10648 | No |
| part type | Engine Intake Manifold |
| Plenum Finish | Cast |
| Product Type | Intake Manifold |
| 6645 | 10.25 |
| 10645 | No |
| 10649 | No |
| Single Or Dual Plane Type | Single |
| Sub Category | Cylinder Block Components |
| 10646 | 2.28 |
| Throttle Body Gasket Included | No |
| 10626 | No |
| Vacuum Ports | Yes |
| Warning | California Proposition 65 |
| Warranty | Manufacturer's Limited 90 Day Warranty |
| Description_ABR | MANIFOLD STE |
| Description_SHO | WEIAND STEALTH RAM |
| Description_INV | MANIFOLD, STEALTHRAM |
| Description_ASC | Use Holley 2x58mm billet throttle body (p/n 112-503 or 112-507) or stock TPI throttle body. Requires use of small cap distributor. Manifold features universal mounting bolt design engineered to accommodate both straight and angled center manifold bolts (requires P/N 90748 Weiand bolt kit for 1987 & later cast iron). Accepts stock or Lokar® TPI kickdown brackets. May require additional sealing modifications for high boost blow through applications.Will not fit Corvette due to manifold height |
| Description_DES | Weiand Stealth Ram Intake - Chevy Small Block V8 |
| Description_EXT | Stealth Ram™ Intake Manifold 1957-86; 262-400 Small Block Chevy V8, 1987-later with aluminum heads - satin |
| Description_MKT | The Weiand Stealth Ram™ intake is a revolutionary, radical departure from the ordinary. Designed to take advantage of the benefits associated with high ram manifolds, it combines aggressive race inspired looks with the drivability of EFI. Designed primarily as a component of the Holley Stealth Ram™/Commander 950 EFI system, the manifold is now available for retrofit on L98 TPI engines and other street/strip machines utilizing standard or 1987 and later aluminum Chevy cylinder heads. The manifold is designed to accept OEM and aftermarket TPI throttle bodies and includes provisions for mounting bracketry necessary for kickdown, cruise and throttle cables. Whether you are looking for more power for that late 80's Camaro or a new look for your street machine, look to Weiand. |
| Description_FAB | Precision CNC machining |
| Description_FAB | No EGR Provisions |
| Description_FAB | D shaped Runners Promote High Flow Rates W/O Turbulence |
| Description_FAB | Satin Finish |
| Description_FAB | 2-Piece Design Features short Individual Runners & a Large Upper Plenum |
| Description_FAB | Power band: Idle to 6500 RPM |
| Description_FAB | Permanent Mold Casting |
| Description_ABR | MANIFOLD STE |
| Description_SHO | WEIAND STEALTH RAM |
| Description_INV | MANIFOLD, STEALTHRAM |
| Description_ASC | Use Holley 2x58mm billet throttle body (p/n 112-503 or 112-507) or stock TPI throttle body. Requires use of small cap distributor. Manifold features universal mounting bolt design engineered to accommodate both straight and angled center manifold bolts (requires P/N 90748 Weiand bolt kit for 1987 & later cast iron). Accepts stock or Lokar® TPI kickdown brackets. May require additional sealing modifications for high boost blow through applications.Will not fit Corvette due to manifold height |
| Description_DES | Weiand Stealth Ram Intake - Chevy Small Block V8 |
| Description_EXT | Stealth Ram™ Intake Manifold 1957-86; 262-400 Small Block Chevy V8, 1987-later with aluminum heads - satin |
| Description_MKT | The Weiand Stealth Ram™ intake is a revolutionary, radical departure from the ordinary. Designed to take advantage of the benefits associated with high ram manifolds, it combines aggressive race inspired looks with the drivability of EFI. Designed primarily as a component of the Holley Stealth Ram™/Commander 950 EFI system, the manifold is now available for retrofit on L98 TPI engines and other street/strip machines utilizing standard or 1987 and later aluminum Chevy cylinder heads. The manifold is designed to accept OEM and aftermarket TPI throttle bodies and includes provisions for mounting bracketry necessary for kickdown, cruise and throttle cables. Whether you are looking for more power for that late 80's Camaro or a new look for your street machine, look to Weiand. |
| Description_FAB | Precision CNC machining |
| Description_FAB | No EGR Provisions |
| Description_FAB | D shaped Runners Promote High Flow Rates W/O Turbulence |
| Description_FAB | Satin Finish |
| Description_FAB | 2-Piece Design Features short Individual Runners & a Large Upper Plenum |
| Description_FAB | Power band: Idle to 6500 RPM |
| Description_FAB | Permanent Mold Casting |
