Hedman Hedders Long-Tube EO Headers For 78-87 GM A-Body/G-Body Cars with 231 V6 68410
Specifications:
| Description_DEF | [B@38babde |
| Description_DES | [B@1dcd3b4c |
| Description_EXT | [B@254eb52b |
| Description_FAB | [B@cb7b803 |
| Description_FAB | [B@523c3710 |
| Description_FAB | [B@26df7140 |
| Description_FAB | [B@76686f5d |
| Description_FAB | [B@47aea633 |
| Description_FAB | [B@74999d61 |
| Description_INV | [B@2991a7c3 |
| Description_SHO | [B@1c36272b |
| Title | HEDMAN HEDDERS STANDARD UNCOATED HEADERS; 1-1/2 IN. TUBE DIA.; 2-1/2 IN. COLL.; FULL LENGTH DESIGN |
| Material | Mild Steel |
| Tube Design | Standard |
| LS SWAP | NO |
| Mounting Hardware Included | Yes |
| with A.I.R. System | No |
| with EGR | No |
| Weld-Up | No |
| Tuned | No |
| Bolts/Studs Included | Yes |
| Catalytic Converter(s) Included | No |
| Collector Bolts Included | Yes |
| Crossover Pipe Included | No |
| Gasket Or Seal Included | Yes |
| Header Fasteners Included | Yes |
| Installation Hardware Included | Yes |
| Motor Mounts Included | No |
| Reducers Included | Yes |
| Tube Size | 1-1/2 in. |
| Y-Pipe Included | No |
| Quantity | Sold as a pair. |
| Primary Tube Gauge | 16g |
| Primary Tube Diameter (in) | 1.50 in. |
| Package Contents | Headers, ball and socket reducers (exhaust adapters), gaskets, mounting hardware |
| Header Material | Mild Steel |
| Header Finish | Uncoated |
| Cylinder Head Port Shape | Rectangle |
| Cylinder Head | Stock Profile Heads |
| Header Construction | MILD STEEL- Standard-Duty |
| Replacement Gasket | 27140 |
| Replacement Head Flange Gasket | 27140 |
| California Proposition 65 | WARNING: Cancer. For more info visit www.P65Warnings.ca.gov |
| Variations | 68416 |
| Tube Material Thickness | 16g |
| Tube Diameter | 1-1/2 in. |
| Tube Style | Long Tubes |
| Air Conditioning | Yes |
| Automatic Transmission - Column | Yes |
| Automatic Transmission - Floor | Yes |
| Manual Transmission - Column | No |
| Manual Transmission - Floor | Yes |
| Tube Length | Long Tubes |
| Flange Thickness | 0.3125 in. |
| Exhaust System Dia | 2 in. |
| Reducer Outlet Size | 2 in. |
| Collector Attachment | 2-1/2 in. |
| Collector Diameter | 2-1/2 in. |
| Collector Size | 2-1/2 in. |
| Notes | 78-81 Camaro, Lemans; 78-87 G-Body 231 V6 |
| Collector Style | BALL and SOCKET Style (Gasketless) |
| Key Feature | EO# (Without A.I.R.) |
| Emissions Notes | EO# D167-33 (click here for covered vehicles in document on ARB.CA.GOV website) |
| Contents | Header(s), new bolts, gasket(s) to head, reducer(s) and hardware, instructions |
| Header Style | Long Tube |
| Header Port Shape | Rectangle |
| Port Shape | Rectangle |
| Flange Style | Standard |
| Finish | Uncoated |
| Finish Type | UNCOATED Mild Steel! Shipped with Temporary Paint. |
| E.O. # | Yes |
| Power Steering | Yes |
