Allstar Performance's shock bracket has three 1/2 inch mounting holes spaced 1-1/4 inch apart and is designed to weld to 3 inch axle tubes, giving builders three trailing arm mount locations to choose from. This bracket is sized to work with Allstar's universal trailing arm (T/A) mount bracket family for setting up rear trailing arm geometry, and is finished in natural steel.
Refer to the manufacturer's spec sheet for full dimensions and hole spacing: Allstar Spec Sheet.
Compatibility: Sized to work with Allstar's universal trailing arm (T/A) mount bracket family, such as ALL60050.
FAQ
What is the ALL60051 used for?
It is a shock bracket that welds to a 3 inch axle tube and provides three trailing arm mount locations for Allstar's universal T/A mount brackets.
How many mounting holes does it have and how are they spaced?
It has three 1/2 inch mounting holes spaced 1-1/4 inch apart.
What size axle tube does this bracket fit?
It is designed to weld to 3 inch axle tubes.
What is the finish?
The bracket is made of natural finish steel.
