Bilstein SMX Series - Suspension Shock Absorber 24-296946
Specifications:
| Body Material | Steel |
| Extended Length (IN) | 21.02 |
| Piston Type | Linear |
| Spring Seat Included | No |
| Rebound @ 10"/sec | 275 |
| PartType | Shocks / Struts |
| Body Diameter (ID) | 46mm |
| Collapsed Length (MM) | 329.0 |
| Extended Length (MM) | 534.0 |
| Spring Hardware | N/A |
| Body Design | Stock Mount Smooth Body |
| Collapsed Length (IN) | 12.95 |
| Lower Mount Type | Eye |
| Series | SMX Series |
| Upper Mount Type | Bar Pin |
| Internal Design | Monotube |
| Title | Bilstein Shock Absorbers |
| Prop 65 - Short Label | WARNING: Cancer & Reproductive Harm - www.P65Warnings.ca.gov |
| Prop 65 (Y/N) | Y |
| Segment | Motorsports |
| Boot Included | No |
| Finish | Black Paint |
| Compression @ 10"/sec | 275 |
| Adjustable Damping | Non-Adjustable |
| Description_FAB | 46mm piston design for maximum damping control |
| Description_FAB | Stock mount design for GM metric chassis applications |
| Description_SHO | Shock |
| Description_INV | SMX GM METRIC REAR, 5 |
| Description_DEF | Suspension Shock Absorber |
| Description_LAB | SMX Series - Suspension Shock Absorber |
| Description_DES | SMX Series - Suspension Shock Absorber |
| Description_ASM | No Applications |
| Description_EXT | 46mm Monotube Shock Absorber |
| Description_MKT | Bilstein SMX Series shock absorbers are specifically designed for motorsports applications that mandate the use of stock mount (OE) suspension components. Designed using 46mm monotube technology, the shocks are available in a variety of damping options including dry kit designed specifically to provide the best options for a variety of race track types and conditions. Built in the USA with precision components and top quality controls, the SMX Series shocks deliver Bilstein’s famous fade-free performance and consistency in a factory-mount package that championship winning racers demand. |
| Description_FAB | 46mm piston design for maximum damping control |
