The Sniper 2 Power Distribution Module (PDM) removes the manual process of connecting electrical wires by consolidating them into a single module. Strip the wire ends, slide them into place, and tighten the set screws. It can distribute power to your Holley EFI fuel pump and a fan, with two additional 2-amp circuits available for low current accessories like gauges and trigger relays. An easy-to-read wiring diagram is printed on the lid.
Specifications:
- 3 Relay Channels: 15A Powertrain (Sniper 2 throttle body and ignition system), 25A (fuel pump output), 25A (fan output)
- Finish: Black
- LED status indicators for reviewing live errors at a glance
- Removable cover with wiring diagram built into the lid
- Part Number: 554-200
Requires Holley P/N 558-190 when adding this PDM to Sniper 2 base kits. Draw is 100 mA or less when connected to the battery; a trickle charger is recommended for vehicles that sit for extended periods. Mount in a location not exposed to direct heat sources such as the exhaust system.
FAQ
What does the Sniper 2 PDM connect to?
It provides battery+, battery-, and switched connections for components in a Sniper 2 installation, including the throttle body, fuel pump, HyperSpark ignition, and cooling fan.
Do I need any other parts to add this PDM to my Sniper 2 kit?
Yes, Holley P/N 558-190 is required when adding this PDM to Sniper 2 base kits.
How many relay channels does the PDM have?
Three: a 15A powertrain channel, a 25A fuel pump output, and a 25A fan output.
Where should the PDM be mounted?
In a compact, sealed location under the hood that is not exposed to direct heat sources like the exhaust system.
