Hooker BlackHeart Hooker BlackHeart Mid-Length Headers - Ceramic Coated 70201506-1HKR
Specifications:
| Bolt size | M8 x 1.25 x 25mm |
| Brand | Hooker BlackHeart |
| CARB (California) Compliant | No |
| Category | Exhaust |
| Collector Diameter | 3.00 inch |
| Emission Code | 4 |
| Engine | GM Gen III/IV (LS) |
| Exhaust Series | Hooker BlackHeart |
| Header Finish | Silver Ceramic |
| Header Style | Mid Length |
| part type | Exhaust Header |
| Primary Tube Dia. | 1-7/8 inch |
| Product Type | Headers |
| Sub Category | Exhaust Manifolds |
| Tube Material | Mild Steel |
| Warning | California Proposition 65 |
| Description_ABR | HDR 67-69 F- |
| Description_SHO | HDR 67-69 F-BODY 1-7 |
| Description_INV | 67-69 F-BODY 1-7/8 MID-LGTH LS SWAP HEAD |
| Description_ASC | This Hooker Blackheart product has been designed only for use on vehicles which are equipped with a stock front subframe and stock steering and suspension components. It is not compatible with any Hooker Blackheart product that has been designed specifically for use with Detroit Speed products. 1.) O2 bungs are not present on these headers, but are provided on the related available adapter tubes 2.) Bolt-in compatible with T56, T56 Magnum and 4L60-4L70 transmissions 3.) Installation with a 4L80/4L85 automatic transmission will require trimming to the transmission case bellhousing, installation will older generation GM automatics (TH350, TH400 etc.) may also require trimming to the transmission case bellhousing |
| Description_DES | Hooker BlackHeart Mid-Length Headers - Ceramic Coated |
| Description_EXT | GM LS 1st Gen (Camaro/Firebird) Mid Length Headers 1-7/8, Collector Size 3, Port Shape - round |
| Description_MKT | Hooker BlackHeart LS Swap component systems are 1967-1969 GM F-Body (Camaro and Firebird) and 1968-1974 GM X-Body (Chevy Nova, Pontiac Ventura, Buick Apollo and Oldsmobile Omega) vehicles. This Mid-Length header is finished in a durable silver ceramic coating and features 1 7/8" primary tubing flowing through high quality steel tubing and exiting in a tightly formed 2.5" collector all designed for maximum ground clearance and power generation. |
| Description_FAB | Flat-finished TIG welded flanges provide superior port sealing |
| Description_FAB | Design provides maximum ground clearance available from a set of headers, ideal for extremely low vehicle ride heights |
| Description_FAB | Bend geometry optimized for superior spark plug serviceability and plug boot/wire clearance |
| Description_FAB | Compatible with OE manual, OE power (Saginaw 800), 3rd-gen F-body, 1983-88 G-body quick ratio and Delphi 600 series steering boxes |
| Description_FAB | Available adapters provide bolt-in connection to Hooker 2.5” and 3” exhaust systems for this vehicle application |
| Description_FAB | Ceramic coated steel construction provides improved thermal efficiency, corrosion resistance and visual appearance over painted steel versions of these headers |
This Part Fits:
| Year | Make | Model | Submodel | Notes |
|---|---|---|---|---|
| 1973 | Buick | Apollo | Base | LS Swap,LS Swap |
| 1974 | Buick | Apollo | Base | LS Swap,LS Swap |
| 1967 | Chevrolet | Camaro | Base | LS Swap,LS Swap,LS Swap |
| 1968 | Chevrolet | Camaro | Base | LS Swap,LS Swap,LS Swap |
| 1969 | Chevrolet | Camaro | Base | LS Swap,LS Swap,LS Swap |
| 1967 | Chevrolet | Camaro | RS | LS Swap,LS Swap,LS Swap |
| 1968 | Chevrolet | Camaro | RS | LS Swap,LS Swap,LS Swap |
| 1969 | Chevrolet | Camaro | RS | LS Swap,LS Swap,LS Swap |
| 1967 | Chevrolet | Camaro | SS | LS Swap,LS Swap,LS Swap |
| 1968 | Chevrolet | Camaro | SS | LS Swap,LS Swap,LS Swap |
| 1969 | Chevrolet | Camaro | SS | LS Swap,LS Swap,LS Swap |
| 1967 | Chevrolet | Camaro | Z28 | LS Swap,LS Swap,LS Swap |
| 1968 | Chevrolet | Camaro | Z28 | LS Swap,LS Swap,LS Swap |
| 1969 | Chevrolet | Camaro | Z28 | LS Swap,LS Swap,LS Swap |
| 1968 | Chevrolet | Chevy II | Nova | LS Swap |
| 1969 | Chevrolet | Nova | Base | LS Swap,LS Swap,LS Swap,LS Swap,LS Swap,LS Swap |
| 1970 | Chevrolet | Nova | Base | LS Swap,LS Swap,LS Swap,LS Swap,LS Swap,LS Swap |
| 1971 | Chevrolet | Nova | Base | LS Swap,LS Swap,LS Swap,LS Swap,LS Swap,LS Swap |
| 1972 | Chevrolet | Nova | Base | LS Swap,LS Swap,LS Swap,LS Swap,LS Swap,LS Swap |
| 1973 | Chevrolet | Nova | Base | LS Swap,LS Swap,LS Swap,LS Swap,LS Swap,LS Swap |
| 1974 | Chevrolet | Nova | Base | LS Swap,LS Swap,LS Swap,LS Swap,LS Swap,LS Swap |
| 1973 | Chevrolet | Nova | Custom | LS Swap,LS Swap |
| 1974 | Chevrolet | Nova | Custom | LS Swap,LS Swap |
| 1973 | Oldsmobile | Omega | Base | LS Swap,LS Swap |
| 1974 | Oldsmobile | Omega | Base | LS Swap,LS Swap |
| 1968 | Pontiac | Acadian | Base | LS Swap,LS Swap,LS Swap,LS Swap |
| 1969 | Pontiac | Acadian | Base | LS Swap,LS Swap,LS Swap,LS Swap |
| 1970 | Pontiac | Acadian | Base | LS Swap,LS Swap,LS Swap,LS Swap |
| 1971 | Pontiac | Acadian | Base | LS Swap,LS Swap,LS Swap,LS Swap |
| 1967 | Pontiac | Firebird | 326 | LS Swap |
| 1968 | Pontiac | Firebird | 350 | LS Swap,LS Swap |
| 1969 | Pontiac | Firebird | 350 | LS Swap,LS Swap |
| 1969 | Pontiac | Firebird | 350 HO | LS Swap |
| 1967 | Pontiac | Firebird | 400 | LS Swap,LS Swap,LS Swap |
| 1968 | Pontiac | Firebird | 400 | LS Swap,LS Swap,LS Swap |
| 1969 | Pontiac | Firebird | 400 | LS Swap,LS Swap,LS Swap |
| 1967 | Pontiac | Firebird | Base | LS Swap,LS Swap,LS Swap |
| 1968 | Pontiac | Firebird | Base | LS Swap,LS Swap,LS Swap |
| 1969 | Pontiac | Firebird | Base | LS Swap,LS Swap,LS Swap |
| 1967 | Pontiac | Firebird | HO | LS Swap,LS Swap |
| 1968 | Pontiac | Firebird | HO | LS Swap,LS Swap |
| 1967 | Pontiac | Firebird | Sprint | LS Swap,LS Swap,LS Swap |
| 1968 | Pontiac | Firebird | Sprint | LS Swap,LS Swap,LS Swap |
| 1969 | Pontiac | Firebird | Sprint | LS Swap,LS Swap,LS Swap |
| 1969 | Pontiac | Firebird | Trans Am | LS Swap |
| 1971 | Pontiac | Ventura | Base | LS Swap,LS Swap,LS Swap,LS Swap |
| 1972 | Pontiac | Ventura | Base | LS Swap,LS Swap,LS Swap,LS Swap |
| 1973 | Pontiac | Ventura | Base | LS Swap,LS Swap,LS Swap,LS Swap |
| 1974 | Pontiac | Ventura | Base | LS Swap,LS Swap,LS Swap,LS Swap |
| 1973 | Pontiac | Ventura | Custom | LS Swap,LS Swap |
| 1974 | Pontiac | Ventura | Custom | LS Swap,LS Swap |
| 1974 | Pontiac | Ventura | GTO | LS Swap |
