This Borgeson steel splined steering shaft carries a 3/4in.-36 spline pattern and can be trimmed up to 1in. off either end for a precise custom fit.
Specifications:
- Steel construction
- 3/4in.-36 spline
- 36in. overall length
- Splined 1 end only (2in. of spline on the splined end)
- Trimmable up to 1in. per end
- Made in the USA
- Part Number: 409036
FAQ
Can this shaft be cut to length?
Yes, it can be trimmed up to 1in. off each end for a precise fit.
How many ends are splined?
Only one end is splined; the other is unsplined.
What spline pattern does it use?
3/4in.-36 spline.
What lengths are available?
Borgeson steel splined shafts are available in 2in. increments from 2in. up to 36in.
